Fully Automatic Paper Cup Machine
Ruian Take Off Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of fully automatic paper cup machine in China. If you're going to buy high quality fully automatic paper cup machine, welcome to get more information from our factory. For price consultation, contact us.
Parameter
|
Name |
PAPER CUP MACHINE |
|
|
Model |
TO-S800型 |
|
|
Paper Cup Size |
3-16 OZ |
|
|
Raw Material |
One-side or two-side PE coated paper(Singe PE or Double PE coated paper) |
|
|
Speed |
75-85 pcs/min |
|
|
Suitable paper weight |
100-300g/㎡；±20g/㎡ |
|
|
Voltage supply |
380V(220V) 50HZ |
|
|
cup size |
bottom35-70mm，top45-90mm，high32-135mm |
|
|
Working Air Source |
0.4-0.6Mpa; 0.4m³/min |
|
|
General power |
6kw |
|
|
Net weight |
2000kg |
|
| Measurement (mm) |
Main machine |
L:2100mm;W:1200mm;H:1800mm
|
|
Cup collector 100kgs |
L:900mm;W:600mm;H:1500mm |
|
|
Cup Side Sealing |
EVERGREEN Ultrasonic |
|
|
Bottom Knurling |
Heat blowing air |
|
1.paper cup machine technology:
A cup-pulling cup-dropping device, comprising a workbench, a cup-dropping unit arranged on the workbench, to
and a curling forming unit arranged on one side of the cup dropping unit. The cup drop unit includes a
The cup-dropping rotating shaft on the stage, a cup-dropping rotating disc set on the cup-dropping rotating shaft, and a plurality of cup-dropping rotating discs arranged on the cup-dropping rotating shaft
Paper cup mounts on the tray for mounting paper cups, and a suction cup device provided on the workbench. the suction cup
The device includes a lift tube inserted on the worktable, a suction cup plate arranged at one end of the lift tube, and
A suction cup hole provided on the suction cup plate. The lift pipe and the suction cup hole communicate with each other. The hemming form
The element includes a hemming rotation shaft arranged on the worktable, and a hemming rotation shaft arranged on the hemming rotation shaft
disc, a plurality of hemming forming dies arranged on the hemming rotating disc, and a cup holder set on the working table
set. Each of the hemming forming molds includes a mold body disposed on the hemming rotating disk, and a mold body disposed on the hemming rotating disk.
The axial accommodating through hole of the mold body, and an end head disposed at one end of the accommodating through hole facing away from the cup holder
forming grooves. The cup holder device includes a cup holder lift drive unit arranged on the worktable, and a
A cup tray unit provided on the cup tray lift drive unit. The cup holder unit includes a
A sliding lifting platform, and at least one cup holder plate arranged on the sliding lifting platform. When the paper cup is rolled, the suction
The cup device is in the same line as the central axis of one of the curling forming molds and one of the paper cup mounting parts, and any
The central axis of one of the cup trays is coincident with the central axis of one of the hemming forming molds, so as to realize the drop and drop of the paper cup.
FAQ
1) If there is a spare part need to replace, what can I do?
We supply all the spare parts for our printer. If any part is broken, we will fix it or send you new parts after users send back the broken ones. We suggest that customers order some spare parts package for long time maintenance and fast replacement.
2) How much taxes should we pay?
Please contact your local Customs or import agent for details. Thanks.
