Film Slitting Machine
Ruian Take Off Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of film slitting machine in China. If you're going to buy high quality film slitting machine, welcome to get more information from our factory. For price consultation, contact us.
Product Introduction
Film slitting machines are sophisticated industrial apparatuses engineered to slice large rolls of film materials into narrower strips with precision, catering to diverse manufacturing needs across multiple industries. These machines play a crucial role in streamlining the production process, ensuring high - quality output, and enhancing overall productivity.
Product Performance:
|
Model |
SYF-1300K |
SYF-1600K |
SYF-2000K |
|
Max.Width of unwinding |
1300mm |
1600mm |
2000mm |
|
Max.Diameter of unwinding |
1600mm |
1600mm |
2000mm |
|
Min. Width of slitting |
50mm(up to materials) |
50mm(up to materials) |
50mm(up to materials) |
|
Max. Diameter ofrewinding |
1500mm |
41500mm |
1500mm |
|
Speed |
10-500m/min |
10-500m/min |
10-500m/min |
|
Total power |
48kw |
59kw |
70kw |
|
Power supply |
380V/50hz |
380V/50hz |
380V/50hz |
|
Weight |
12000kg |
14000kg |
16000kg |
|
Overall dimension (LxWxH) |
7500x3500x2400(mm) |
7500x3800x2400(mm) |
7500x4200x2400(mm) |
Product characteristics:
High - Speed Operation
Exceptional Speed Capabilities: Film slitting machines are designed to operate at high speeds, with some models capable of slitting films at speeds ranging from 500 to 1500 meters per minute, depending on the type of film and the machine's design. For example, in the packaging industry, where large volumes of film are processed daily, high - speed slitting machines can significantly increase production throughput, meeting the demands of mass production.
Fast Acceleration and Deceleration: These machines are engineered to reach their maximum operating speed rapidly and decelerate smoothly when required. This is crucial for minimizing the time lost during start - up and shutdown processes. Fast acceleration allows for quicker production start - up, while smooth deceleration ensures that the film is not damaged during the shutdown phase. This feature further enhances the overall productivity of the machine.
High Precision
Narrow Tolerances: Film slitting machines are capable of achieving extremely high slitting precision. The slitting width accuracy can be within a very small range, often ±0.1mm or even less in some high - end models. This level of precision is essential for applications where tight dimensional tolerances are critical, such as in the electronics industry when slitting films for use in printed circuit boards or in the production of optical films for displays.
Consistent Cut Quality: The use of high - quality cutting tools and advanced control systems ensures that the cut edges of the slit film are clean, smooth, and free from burrs or fraying. This consistent cut quality is vital for downstream processes, such as printing, laminating, or further processing into finished products. It reduces waste and rework, as the slit film can be directly used in subsequent manufacturing steps without the need for additional finishing operations.
