Adult Diaper Machine

Ruian Take Off Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of adult diaper machine in China. If you're going to buy high quality adult diaper machine, welcome to get more information from our factory. For price consultation, contact us.

Adult diaper machine

Adult pull up diaper machine

Adult pull up diaper machine drawing

a) MAIN PARAMETERS:

1. Product size：XL、L、M, three sizes;

2. Product structure:

Dual Phobic nonwoven, Philic nonwoven、ADL、core(Lower tisue+anatomic core&SAP mixed+direct core&SAP mixed+ Lower tisue)、Laminated nonwoven、Pe film、Frontal tape, Side tape double pieces,Leak cuff elastic、Leg elastic, Waistband

3. Core structure：as per requirement.

4. Design speed：350pcs\min(Medium size)

5. Production speed: 300pcs\min(Medium size)

6. Center line distance: Materials center to frame board distance: 600mm.

7. Raw materials：upper is absorbent layer, backsheet is lower.

8. Product weight tolerance：±5%;

9. Wastage：≤4.0%（Excluding glue, splice, raw jointer defectives）

10. Efficiency：≥85%

11. Installation：about 620KW（glue machine & air compressor not included）

12. Power supply：380 V 、50Hz (3 phases, 4 lines, ground-in)（380-420V is ok）

13. Air compressor：0.6-0.8Mpa（customer prepared）

14. Machine sizes（L×W×H）：43m×9m×5.5m（Including mill, pulp & stacker）

15. Machine direction: face the machine pending ;

16. Machine color: pending.

MAIN PARAMETERS:

1. Strong firm structure, face board 30mm thickness after CNC treated, frame is 60mm steel square bar, bottom frame is 150mm×150mm bar, driven cabin is

1100mm width, easy for the maintenance, pedal equipped.

2. Mill system(Alloy blade)crusher system（800KG/H+600KG/H）

1) Pulp stand, electric drive auto lifting device, auto change roll without machine stop.

2）Saw-type high speed mill, treated, untreated & semi-treated pulp available.

3）Pulp feeding, use servo motor control, auto adjusting the pulp dosing via speed change, to guarantee fluff weight balance at high or lower speed running.

4）With sensors to auto alarm at bearings overheating.

3. Fluff Forming system：

1）Double drummer, continue type , anatomic core.

2）Fluff vacuum adopt the side sucking mode, extending the vacuum area, to make fluff high density and soften.

3）SAP spray and mix-up fluff.

4）Separated chambers forming: distribution layer（Non-SAP）、Mix-layer（SAP mixed）、bottom layer（non-SAP）.

5）Height adjusted rotating brush, to control fluff thickness even.

6）Vacuum fan power ≥ 90KW one piece, 45KW one piece

7）Dust filter & recycle device (option, standard: clothbag)

8）Big core: core bare & grid press

4. SAP spray system（Ⅰ）：

1）Spray range: 3-10g/pc.

2）Servo control, spray gram is to setup by Interface.

3）Flat belt pushing, mixing-up fluff.

4）Continued spray even, Heater Before Dispense

5）Lower position alarm function.

6）SAP sensor alarm & auto ground feeding to hopper.
